USPs

Multiple User Credentials

Multiple User Credentials
  • Biometric: Finger
  • RFID Cards
Multiple User Credentials

Convenient Communication Options

Convenient Communication Options
  • RS-232
  • RS-485
  • Fetch Power from Device
Convenient Communication Options

Constant Status Monitoring

Constant Status Monitoring
  • Shows User Access Status
  • Shows Device Status
Constant Status Monitoring

Features

Secured Communication

Secured Communication

Secure data transmission with SSL encryption, providing a highly reliable solution that is snoop-proof and hack-proof

Secured Communication

Tamper Detection

Tamper Detection

Provides better security with tamper detection, instantly alerting to any vandalism acts, ensuring enhanced protection for devices

Tamper Detection

Weather Resistance with IP65

Weather Resistance with IP65

Offers weather resistance with an IP65 rating, providing reliable ingress protection against dust and water, making it ideal for outdoor applications

Weather Resistance with IP65

Superior Design

Superior Design

Features a superior design that not only enhances the product's lifespan but also significantly improves performance, all while providing an appealing aesthetics

Superior Design

Buzzer

Buzzer

Provides audio alert, enhancing security by pointing to events such as access violations in real-time

Buzzer

Seamless Access Control

Seamless Access Control

Offers access with dual verification, combining convenience with higher security measures for seamless and reliable access control

Seamless Access Control

Applications

Access Control

Access Control

Access Control

Request a Quote

Architecture Diagram

Cosec Path Series Access Control Reader Architecture Diagram

Technical Specifications

cosec-path-series-path-rdfx-1
cosec-path-series-path-rdfx-2
cosec-path-series-path-rdfx-3
cosec-path-series-path-rdfx-4

Fingerprint and Card-Based Access Control Reader

  • Multi-Credential Support – Fingerprint and RFID Card
  • Multi-Connectivity Options – RS-232, RS-485
  • Compact Design with IP65 Rating
GENERAL

Credentials Supported

  • FIngerprint and RFID Card

RF Option

  • COSEC PATH RDFE:- EM Proximity Card
    COSEC PATH RDFM:- MIFARE Classic®, DESFire EV1 and EV2(Read/Write)/ NFC Tag
    COSEC PATH RDFI:- HID i-Class/ Mifare/ Desfire/ Combo Cards

    *MIFARE and MIFARE Classic® are trademarks of NXP B.V.
CAPACITY

Template Capacity

  • 9,600 (1:N Mode)

Event log

  • No
COMMUNICATION

RS-485

  • Yes

RS-232

  • Yes
HARDWARE

Reset Switch

  • Yes

Tamper Detection

  • Yes
SENSOR

Sensor Name

  • Suprema Sensor

Sensor Technology

  • Optical

Encryption

  • 256-bit AES

Water-proof

  • Yes

False Acceptance Ratio (FAR)

  • 0.00001

False Rejection Ratio (FRR)

  • 0.0001

Resolution (DPI)

  • 500 dpi

Sensing Area

  • 16.00mm x 19.00mm

Template Size

  • 384 Bytes

Image Size (Pixel)

  • 272mm x 320mm
AUDIO VISUAL

LED

  • Yes (Tri Color)

Buzzer

  • Yes (61 dbA@30cm)
ENVIRONMENTAL

Operating Temperature

  • 0 °C to +50°C (32°F to 122°F)

Relative Humidity

  • 5% to 95 % RH Non-Condensing
POWER

Power

  • 12 VDC @ 0.1A
MECHANICAL

Dimensions

  • 50mm x 136mm x 33mm

Weight

  • 0.27 Kgs (0.59 lbs)

Ingress Protection

  • IP65
INSTALLATION

Mounting

  • Vertical wall mounting
cosec-path-series-path-rdcx-1
cosec-path-series-path-rdcx-2
cosec-path-series-path-rdcx-3
cosec-path-series-path-rdcx-4

Card-Based Access Control Reader

  • Credential Support – RFID Card
  • Multi-Connectivity Options – RS-232, RS-485
  • Compact Design with IP65 Rating
GENERAL

Credentials Supported

  • RFID Card

RF Option

  • COSEC PATH RDCE:- EM Proximity Card
    COSEC PATH RDCM:-MIFARE Classic®, DESFire EV1 and EV2(Read/Write)/ NFC Tag
    COSEC PATH RDCI:-HID i-Class/ Mifare/ Desfire/ Combo Cards

    *MIFARE and MIFARE Classic® are trademarks of NXP B.V.
CAPACITY

Event log

  • No
COMMUNICATION

RS-485

  • Yes

RS-232

  • Yes
HARDWARE

Finger Sensor

  • NA

Reset Switch

  • Yes

Tamper Detection

  • Yes
AUDIO VISUAL

LED

  • Yes (Tri Color)

Buzzer

  • Yes (61 dbA@30cm)
ENVIRONMENTAL

Operating Temperature

  • 0 °C to +50°C (32°F to 122°F)

Relative Humidity

  • 5% to 95 % RH Non-Condensing
POWER

Power

  • 12 VDC @ 0.1A
MECHANICAL

Dimensions

  • 50mm x 136mm x 33mm

Weight

  • 0.27 Kgs (0.59 lbs)

Ingress protection rate

  • IP65
INSTALLATION

Mounting

  • Vertical wall mounting

Certifications

CE
FCC
RoHS
