Overview

Matrix SIMADO GFX11 is a simple and reliable GSM FCT gateway for small businesses and remote areas. It connects analog devices to GSM networks for smooth communication. The GFX11E variant includes a battery backup, making it ideal for emergency use. Designed for locations with poor landline access, it ensures businesses stay connected and maintain operations even in critical times.

USPs

GSM/4G Connectivity to Existing PBX

  • GSM FCT Gateway enables Seamless Integration of GSM/4G Connectivity with GSM/4G Networks
  • Make Mobile Calls from Analog Extensions
  • Fixed-to-mobile Call Feasibility Optimization

Secure Network Bridging

  • Secure Connection between GSM/4G Networks and Internal PBX Infrastructure with GSM FCT Gateway
  • Emergency Number Dialing, Even in the Absence of SIM Card
  • Restrict Unwanted Calls through List of Denied Numbers
  • Prevention of Unauthorized Access and Data Breaches

Service Provider Lock

  • GSM FCT Gateway Locks Device to Work with Specific Service Provider
  • Locks/Unlocks, even when a SIM Card is not Inserted
  • Compatibility with Multiple GSM Service Providers
  • Flexibility to Change or Update the Locked Service Provider

Features

Quad-band, LTE Support

Quad-band, LTE Support

Seamless communication and connectivity through the latest cellular technology using GSM FCT Gateway

Quad-band, LTE Support

Automatic Number Translation

Automatic Number Translation

Converts dialed numbers to their corresponding destination numbers for seamless and accurate call handling

Automatic Number Translation

Call Detail Record

Call Detail Record

Comprehensive and detailed information about each call for monitoring, analysis, and billing purposes using GSM FCT Gateway

Call Detail Record

Allowed and Denied List

Allowed and Denied List

Manage call permissions by specifying which numbers are permitted or blocked, ensuring effective call management and security

Allowed and Denied List

Hotline Extension Setting

Hotline Extension Dialing

GSM FCT Gateway automatically establishes a call without dialing, streamlining communication and improving responsiveness

Hotline Extension Setting

Emergency Number Dialing

Emergency Number Dialing

Direct and immediate access to emergency services for prompt assistance and peace of mind

Emergency Number Dialing

CLI Display

CLI Display

Real-time caller information on the connected devices for efficient call handling and personalized communication through GSM FCT Gateway

CLI Display

Multi-stage Dialing

Multi-stage Dialing

Efficient and reliable communication connections across multiple networks or destinations

Multi-stage Dialing

Polarity Reversal

Polarity Reversal

Seamless communication connectivity and compatibility allows reliable and efficient transmission of voice signals through GSM FCT Gateway

Polarity Reversal

Architecture Diagram

SIMADO GFX11: GSM-FCT Gateway Architecture Diagram

Technical Specifications

SIMADO-GFX11_001
SIMADO-GFX11_002
SIMADO-GFX11_003
SIMADO-GFX11_004

  • 1 GSM Port
  • 1 FXS Port
  • 1 SMA Antenna
  • Supports 2G Connectivity
  • 12V DC Power (Adaptor Based)

SIMADO GFX11

  • GSM (2G) FCT for Voice Applications
Mobile Port

GSM/4G SIM Cards

  • 1

Frequency Bands

  • Quad-band GSM850, EGSM900, DCS1800, PCS1900, UMTS850, UMTS900, UMTS1900, UMTS2100, PCS1900 Tri-band WCDMA 850/1900/2100 MHz or Tri-band WCDMA 900/1900/2100 MHz

SIM Interface

  • 1.8, 3V SIM Interface

Compliance

  • ETSI GSM Phase2/2+
FXS Port

Connector

  • RJ11

Dialling and Reception

  • Pulse and DTMF Dialling

CLIP

  • DTMF and FSK CLI Presentation

Answering and Disconnect Signalling

  • Polarity Reversal for Call Connect/Disconnect Signalling
Power Supply

Input

  • External Power Adaptor 100-240 VAC, 47-63Hz Output: 12VDC@1.25A

Power Consumption

  • 5W (Typical)
Other

Dimensions (W x H x D)

  • 133.5 x 198 x 44.6 mm

Mounting Options

  • Wall Mount and table Top

Operating Temperature

  • 0°C to +45°C (34°F to +133°F)
SIMADO-GFX11_001 4G
SIMADO-GFX11_002 4G
SIMADO-GFX11_003 4G
SIMADO-GFX11_004 4G

  • 1 GSM/4G Port
  • 1 FXS Port
  • 1 SMA Antenna
  • Supports 4G Connectivity
  • 12V DC Power (Adaptor Based)

SIMADO GFX11 4G

  • GSM (2G/3G/4G) FCT for Voice Applications
Mobile Port

GSM/4G SIM Cards

  • 1

Frequency Bands

  • Quad-band GSM850, EGSM900, DCS1800, PCS1900, UMTS850, UMTS900, UMTS1900, UMTS2100, PCS1900 Tri-band WCDMA 850/1900/2100 MHz or Tri-band WCDMA 900/1900/2100 MHz

SIM Interface

  • 1.8, 3V SIM Interface

Compliance

  • ETSI GSM Phase2/2+
FXS Port

Connector

  • RJ11

Dialing and Reception

  • Pulse and DTMF Dialing

CLIP

  • DTMF and FSK CLI Presentation

Answering and DIsconnect Signalling

  • Polarity Reversal for Call Connect/Disconnect Signalling
Power Supply

Input

  • External Power Adaptor 100-240 VAC, 47-63Hz Output: 12VDC@1.25A

Power Consumption

  • 5W (Typical)
Other

Dimensions (W x H x D)

  • 133.5 x 198 x 44.6 mm

Mounting Options

  • Wall Mount and Table Top

Operating Temperature

  • 0°C to +45°C (34°F to +133°F)
SIMADO-GFX11E_02
SIMADO-GFX11E_03
SIMADO-GFX11E_01
SIMADO-GFX11E_04

  • 1 GSM Port
  • 1 FXS Port
  • 1 SMA Antenna
  • Supports 2G Connectivity
  • Built-in Battery Back-up
  • 12V DC Power (Adaptor Based)

SIMADO GFX11E

  • GSM (2G) FCT for Emergency Applications
Mobile Port

GSM/4G SIM Cards

  • 1

Frequency Bands

  • Quad-band GSM850, EGSM900, DCS1800, PCS1900, UMTS850, UMTS900, UMTS1900, UMTS2100, PCS1900 Tri-band WCDMA 850/1900/2100 MHz or Tri-band WCDMA 900/1900/2100 MHz

SIM Interface

  • 1.8, 3V SIM Interface

Compliance

  • ETSI GSM Phase2/2+
FXS Port

Connector

  • RJ11

Dialing and Reception

  • Pulse and DTMF Dialing

CLIP

  • DTMF and FSK CLI Presentation

Answering and Disconnect Signalling

  • Polarity Reversal for Call Connect/Disconnect Signalling
Power Supply

Input

  • External Power Adaptor 100-240 VAC, 47-63Hz Output: 12VDC@1.25A

Battery Back-up

  • 4 hours (idle mode), 2 hours (talking mode)

Power Consumption

  • 5W (Typical)
Other

Dimensions (W x H x D)

  • 133.5 x 198 x 44.6 mm

Mounting Options

  • Wall Mount and Table Top

Operating Temperature

  • 0°C to +45°C (34°F to +133°F)
SIMADO-GFX11E_02 4G
SIMADO-GFX11E_03 4G
SIMADO-GFX11E_01 4G
SIMADO-GFX11E_04 4G

  • 1 GSM/4G Port
  • 1 FXS Port
  • 1 SMA Antenna
  • Supports 4G Connectivity
  • Built-in Battery Back-up
  • 12V DC Power (Adaptor Based)

SIMADO GFX11E 4G

  • GSM (2G/3G/4G) FCT for Emergency Applications
Mobile Port

GSM/4G SIM Cards

  • 1

Frequency Bands

  • Quad-band GSM850, EGSM900, DCS1800, PCS1900, UMTS850, UMTS900, UMTS1900, UMTS2100, PCS1900 Tri-band WCDMA 850/1900/2100 MHz or Tri-band WCDMA 900/1900/2100 MHz

SIM Interface

  • 1.8, 3V SIM Interface

Compliance

  • ETSI GSM Phase2/2+
FXS Port

Connector

  • RJ11

Dialing and Reception

  • Pulse and DTMF Dialing

CLIP

  • DTMF and FSK CLI Presentation

Answering and Disconnect Signalling

  • Polarity Reversal for Call Connect/Disconnect Signalling
Power Supply

Input

  • External Power Adaptor 100-240 VAC, 47-63Hz Output: 12VDC@1.25A

Battery Back-up

  • 4 hours (idle mode), 2 hours (talking mode)

Power Consumption

  • 5W (Typical)
Other

Dimensions (W x H x D)

  • 133.5 x 198 x 44.6 mm

Mounting Options

  • Wall Mount and Table Top

Operating Temperature

  • 0°C to +45°C (34°F to +133°F)
