Digital PBX with 40+ Call Management Features

  • 3-Participants Conference
  • Abbreviated Dialing
  • 100% Non-Blocking Routing
  • Advanced Call Routing
  • Call Recording and Voicemail

Power Fail-transfer

  • Digital PBX prevents Data Loss in the Event of Power Loss
  • Efficient Work in All-condition
  • Failover Mechanisms for Power
  • Uninterrupted Communication ensures Business Continuity
  • Enhances Emergency response Capabilities

Digital PBX with Live Call Supervision

  • Monitor Calls Made/Received by an Extension
  • Call Quality Monitoring and Analysis
  • Lessen Misconduct and Maintain Privacy
  • Ensure Quality Customer Interactions

Features

allowed-and-denied-list

Allowed and Denied List

Digital PBX restricts calling as per convenience

allowed-and-denied-list

least-cost-routing

Least Cost Routing

Ensure least cost incurred for each call

least-cost-routing

auto-attendant

Auto-attendant

Digital PBX effortlessly guides callers to the right extension

auto-attendant

3-participant-conference

3-participant Conference

Connect three participants in a single conference through Digital PBX

3-participant-conference

auto-call-back

Auto Call Back

Digital PBX redials busy or unanswered numbers ensuring prompt and efficient communication

auto-call-back

100-non-blocking

100% Non-blocking

Allow simultaneous handling of multiple calls without any congestion or delays through Digital PBX

100-non-blocking

abbreviated-dialing

Abbreviated Dialing

Digital PBX allows users to assign and dial short codes for frequently called numbers

abbreviated-dialing

dynamic-lock

Dynamic Lock

Dynamically adjust access permissions based on user roles and real-time conditions through Digital PBX

dynamic-lock

alternate-number-dialing

Alternate Number Dialing

Digital PBX enables users to easily dial and connect to alternative phone numbers associated with their contacts

alternate-number-dialing

Architecture Diagrams

Technical Specifications

Digital PBX with 2 Trunks and 6 Analog Extensions

  • 2 Trunks and 6 Analog Extensions
  • 40+ Value Added Call Attributes
  • PCM/TDM, Digital Switching, 100% Non-Blocking
  • 16-bit DSP Processor
  • DTMF and Pulse Dialing
  • Over Voltage Secondary Protection

Parameters

Specifications

Type of Switching

  • PCM/TDM, Digital Switching, 100% Non-blocking

Processor

  • 16-bit DSP

Signaling

  • Loop Start

Dialing

  • DTMF and Pulse (10/20PPS)

Off-Hook AC Impedance

  • 600/900/Complex

Off-Hook Current

  • 39mA Max.

Loop Limit

  • 1800Ω Max (Excluding Telephone)

On-Hook Voltage (Tip/Ring)

  • -48V nominal

DTMF detection

  • ITU-T Q.24

Return Loss

  • >18dB

Longitudinal Balance

  • >50dB

Transmission Level Adjust

  • Tx Gain: -12dB to +6dB, Rx Gain: -12dB to +6dB

Ringing

  • Trapezoidal 50VRMS/25Hz and Sinusoidal 52VRMS/25Hz

REN

  • 3

CLI Presentation

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202

Protection

  • Over Voltage Secondary Protection

Physical Connector

  • 2.54mm Push Type connector
CO (Central Office)/Two-Wire Trunk (TWT)

Signaling

  • Loop Start

Loop Limit

  • 1200Ω

Off-Hook AC Impedance

  • 600/900/Complex

Pulse Dialling

  • 10/20 PPS

DTMF Dialling and Reception

  • ITU-T Q.23 and Q.24

Return Loss

  • >18dB

Longitudinal Balance

  • >50dB

Transmission Level Adjust

  • Tx Gain: -15dB to +10dB. Rx Gain: -15dB to + 10dB

CLI Reception

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202

Call Maturity

  • Delay and Polarity Reversal

Protection

  • Over Voltage and Over Current Secondary Protection

Physical Connector

  • Over Voltage Secondary Protection

Physical Connector

  • 2.54mm Push Type connector

Input

  • External Adapter 12V@2A for VISIONPRO 206, 308, 412

Dimensions (WxHxD)

  • 23.1×16.25×5.5cm (10.5″x11.2″x3.1″)

Unit Weight

  • 0.65 kg (1.43lbs)

Shipping Weight

  • 3.5 kg (7.7lbs)

Installation

  • Wall Mount

Operating Temperature

  • 0°C to 45 °C (+32°F to +122°F)

Operating Humidity

  • 95% RH, Non-Condensing

Digital PBX with 3 Trunks and 8 Analog Extensions

  • 3 Trunks and 8 Analog Extensions
  • 40+ Value Added Call Attributes
  • PCM/TDM, Digital Switching, 100% Non-Blocking
  • 16-Bit DSP Processor
  • DTMF and Pulse Dialing
  • Over Voltage Secondary Protection

Parameters

Specifications

Type of Switching

  • PCM/TDM, Digital Switching, 100% Non-blocking

Processor

  • 16-bit DSP

Signaling

  • Loop Start

Dialing

  • DTMF and Pulse (10/20PPS)

Off-Hook AC Impedance

  • 600/900/Complex

Off-Hook Current

  • 39mA Max.

Loop Limit

  • 1800Ω Max (Excluding Telephone)

On-Hook Voltage (Tip/Ring)

  • -48V nominal

DTMF detection

  • ITU-T Q.24

Return Loss

  • >18dB

Longitudinal Balance

  • >50dB

Transmission Level Adjust

  • Tx Gain: -12dB to +6dB, Rx Gain: -12dB to +6dB

Ringing

  • Trapezoidal 50VRMS/25Hz and Sinusoidal 52VRMS/25Hz

REN

  • 3

CLI Presentation

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202

Protection

  • Over Voltage Secondary Protection

Physical Connector

  • 2.54mm Push Type connector
CO (Central Office)/Two-Wire Trunk (TWT)

Signaling

  • Loop Start

Loop Limit

  • 1200Ω

Off-Hook AC Impedance

  • 600/900/Complex

Pulse Dialling

  • 10/20 PPS

DTMF Dialling and Reception

  • ITU-T Q.23 and Q.24

Return Loss

  • >18dB

Longitudinal Balance

  • >50dB

Transmission Level Adjust

  • Tx Gain: -15dB to +10dB. Rx Gain: -15dB to + 10dB

CLI Reception

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202

Call Maturity

  • Delay and Polarity Reversal

Protection

  • Over Voltage and Over Current Secondary Protection

Physical Connector

  • Over Voltage Secondary Protection

Physical Connector

  • 2.54mm Push Type connector

Input

  • External Adapter 12V@2A for VISIONPRO 206, 308, 412

Dimensions (WxHxD)

  • 23.1×16.25×5.5cm (10.5″x11.2″x3.1″)

Unit Weight

  • 0.65 kg (1.43lbs)

Shipping Weight

  • 3.5 kg (7.7lbs)

Installation

  • Wall Mount

Operating Temperature

  • 0°C to 45 °C (+32°F to +122°F)

Operating Humidity

  • 95% RH, Non-Condensing

Digital PBX with 4 Trunks and 12 Analog Extensions

  • 4 Trunks and 12 Analog Extensions
  • 40+ Value Added Call Attributes
  • PCM/TDM, Digital Switching, 100% Non-Blocking
  • 16-Bit DSP Processor
  • DTMF and Pulse Dialing
  • Over Voltage Secondary Protection

Parameters

Specifications

Type of Switching

  • PCM/TDM, Digital Switching, 100% Non-blocking

Processor

  • 16-bit DSP

Signaling

  • Loop Start

Dialing

  • DTMF and Pulse (10/20PPS)

Off-Hook AC Impedance

  • 600/900/Complex

Off-Hook Current

  • 39mA Max.

Loop Limit

  • 1800Ω Max (Excluding Telephone)

On-Hook Voltage (Tip/Ring)

  • -48V nominal

DTMF detection

  • ITU-T Q.24

Return Loss

  • >18dB

Longitudinal Balance

>50dB

Transmission Level Adjust

  • Tx Gain: -12dB to +6dB, Rx Gain: -12dB to +6dB

Ringing

  • Trapezoidal 50VRMS/25Hz and Sinusoidal 52VRMS/25Hz

REN

  • 3

CLI Presentation

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202

Protection

  • Over Voltage Secondary Protection

Physical Connector

  • 2.54mm Push Type connector
CO (Central Office)/Two-Wire Trunk (TWT)

Signaling

  • Loop Start

Loop Limit

1200Ω

Off-Hook AC Impedance

  • 600/900/Complex

Pulse Dialling

  • 10/20 PPS

DTMF Dialling and Reception

  • ITU-T Q.23 and Q.24

Return Loss

  • >18dB

Longitudinal Balance

  • >50dB

Transmission Level Adjust

  • Tx Gain: -15dB to +10dB. Rx Gain: -15dB to + 10dB

CLI Reception

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202

Call Maturity

  • Delay and Polarity Reversal

Protection

  • Over Voltage and Over Current Secondary Protection

Physical Connector

  • Over Voltage Secondary Protection

Physical Connector

  • 2.54mm Push Type connector

Input

  • External Adapter 12V@2A for VISIONPRO 206, 308, 412

Dimensions (WxHxD)

  • 23.1×16.25×5.5cm (10.5″x11.2″x3.1″)

Unit Weight

  • 0.65 kg (1.43lbs)

Shipping Weight

  • 3.5 kg (7.7lbs)

Installation

  • Wall Mount

Operating Temperature

  • 0°C to 45 °C (+32°F to +122°F)

Operating Humidity

  • 95% RH, Non-Condensing
